Home / Products / ECG / ECG Trunk Cable
| Category | ECG |
|---|---|
| Certifications | FDA, CE, ISO13485,SFDA |
| Connector Distal | Rectangular, 16-pin Draeger Infinity Connector |
| Connector Proximal | Twin Pin Connector and Dual 7-Pin Connectors |
| Latex-free | Yes |
| Lead Color Coding | AHA & IEC |
| Lead Number | Long Trunk, 3 / 5 |
| Packaging Type | Bag |
| Packaging Unit | 1 |
| Patient Size | Adult/Pediatric |
| Resistance | 1K Ohms |
| Sterile | No |
| Total Cable Length | 2.5M |
| Trunk Cable Color | Gray |
| Trunk Cable Length | 2.5M |
| Trunk Cable Material | TPU Jacket |
| Warranty | 6 months |
| Weight | 0.5KG |
| Manufacturer | Model |
|---|---|
| Draeger | Infinity C500, Infinity C700, Infinity Delta, Infinity Delta XL, Infinity Gamma, Infinity Gamma X, Infinity Gamma XL, Infinity Kappa, Infinity Kappa XLT, Infinity Omega S, Infinity Vista, Infinity Vista XL, SC 6000, SC 7000, SC 9000 |
Product No:
| AHA | EA205SM1A-119 |
| IEC | EA205SM1I-119 |
